I need help to make new firmware for DLP Resin printer. I do not need a Ramps controller as the printer have only one axis and the DLP projector is controlled by cretion Workshop program .

So eat i have and what i use is:

1. Ardiuno R3

2. A4988 stepper driver

3. Nema 17 stepper Steps per revolution 200 1.8deg/step (My Z=2560)

4. Lead screw for 7 axis is 8mm x 250mm ( Standard prosa Mendal )

5. One endstop (Mechanical)

Pins Use on ardiuno :

Pin 11 and 12 Z axis up and down.

Pin 7 Stop-End for z

I use for software control : Creation Workshop for DLP printers :


File attached is the file of some other users use and i do not need all the stuff inside. ( UV on and of i do not need , Servo Control and shutter, and other axes i do not need. I only need Z axes and stop end. The rest is the scope and that is controled by Creation software.

Basic and simple
